Wire Cable Connector Terminals 222 4 Pole Quick Push In Plastic Material PA66 Mini Fast Universal Compact Connectors 10PCS
US$ 7.26
US$ 8.84
: In stock
: 62638
Wire Connector Terminals 222 Replace 4 Pole Quick Push In Plastic Material PA66 Fast Connectors 10PCS 1. DESCRIPTION Built-in test point. Quick and easy installation Protection against electrical shock,...
Share:
Wire Connector Terminals 222 Replace 4 Pole Quick Push In Plastic Material PA66 Fast Connectors 10PCS
1. DESCRIPTION
- Built-in test point.
- Quick and easy installation
- Protection against electrical shock, touch safe.
- Low installed cost and safe operation.
2.TECHNICAL PARAMETERS
| Model No. |
VSE-422-A (222-422) |
| Color |
Grey/Orange, other color can be customized |
| Length/Height/Wide (mm) |
39/17/14.5 |
| Connection method |
Cage Clamp |
| Material |
Flame resistant Nylon PA66, also available in PC material |
| Rated Voltage/Current |
400V/32A |
| Cross section, solid Cable/Conductor Size |
0.08-2.5 mm² /28-12 AWG |
| Cross section, soft Cable/Conductor Size |
0.08-4 mm² /28-12 AWG |
| Strip length |
9 -10 mm / 0.35 -0.39 in |
| Mounting Carrier |
222-500, 222-505 |
| Standard |
IEC 60947-7-1 |
| Packing Detail |
4.32g/pc, 150PCS/BOX,4800PCS/CTN |
| Certification |
CE/RoHS/CQC/ISO 9001 |
