OPEN-SMART 0.56" Blue LED 4-Digit Display Module with Decimal Point
US$ 4.47
US$ 6.27
: In stock
: 2000352
The module is based on a decimal point display module, it displays four digital tube (0.56 inches), and driver IC is TM1637, only two signal lines can make MCU control...
Share:
The module is based on a decimal point display module, it displays four digital tube (0.56 inches), and driver IC is TM1637, only two signal lines can make MCU control 4-digit 7-segment LED display. Can be used to display decimal, letters and so on.
The features are as following:
1. 4-digit blue common anode display
2. 8-level adjustable luminance levels
3. Power supply should be DC 3.3~5.25V
4. Interface level can be 5V or 3.3V
5. 4-screw mounting holes whose diameter is 2.2mm
6. Works with official Arduino boards
The features are as following:
1. 4-digit blue common anode display
2. 8-level adjustable luminance levels
3. Power supply should be DC 3.3~5.25V
4. Interface level can be 5V or 3.3V
5. 4-screw mounting holes whose diameter is 2.2mm
6. Works with official Arduino boards
| General | |
|---|---|
| Brand | OPEN-SMART |
| Model | 4-Digit Display v1.0 |
| Quantity | 1 piece |
| Form Color | Blue + Black + White |
| Material | PCB + Plastic |
| Specification | |
| Screen Type | LED Digital Tube |
| Screen Size | 0.56 inch |
| Resolution | Others |
| Working Voltage | 3.3~5.25V |
| Working Current | 80mA |
| English Manual / Spec | Yes |
| Download Link | http://pan.baidu.com/s/1kT6xZyJ |
| Dimensions & Weight | |
|---|---|
| Dimensions | 2.28 in x 0.94 in x 0.47 in (5.8 cm x 2.4 cm x 1.2 cm) |
| Weight | 0.49 oz (14 g) |
| Packing List |
|---|
| 1 x 4-Digit Display (0.56inch) |
