FC-16-K 2-Channel Self-Lock Relay Module - Blue

FC-16-K 2-Channel Self-Lock Relay Module - Blue

US$ 8.23 US$ 12.48

: In stock

: 194104

Model FC-16-K Quantity 1 Color Blue Material PCB Features Dual-panel design PCB, 2-channel independent self-lock design, noninterference; stable and reliable performance chip, good anti-interference performance, not spurious triggering; With high...
Model FC-16-K
Quantity 1
Color Blue
Material PCB
Features Dual-panel design PCB, 2-channel independent self-lock design, noninterference; stable and reliable performance chip, good anti-interference performance, not spurious triggering; With high power stabilivolt to supply enough stable voltage, with enough heat dissipation hole to ensure the module for long time, stable and reliable working; With anti-power reversed diode, will not damage the module if reverse in a short time; Wide range voltage, DC 7~14 power supply can make the module in steady operation; Using SONGLE to control the load, it can bear the load of 250V 10 (AC) and 30V 10 (AC); Can connect the external trigger switch, with connector and lead for convenient to use; The trigger supports other sensor module to trig, it works for low level trigger
Specification Power supply voltage: DC 7~14V, Power supply current: >200mA; Load: 250V 10A (AC) or 30V 10A (Dc); Lifespan: 1,000,000 times
Application Press the trigger button, the relay will connect, press again, it will disconnect; Also can connect external trigger and use the low level trigger; Use to control household appliances, household light, and factory equipment; Use to the small current to control the high voltage power device
English Manual/Spec No, supplies wiring illustration
Packing List 1 x Relay module
  1 x Jumper cap
  1 x 3-pin external trigger cable (50cm)
