NH090100 Intelligent NI-MH battery Adapter for 2.4-7.2V1A Ni-MH / NiCd Battery Charger Pack(6 Plug) - Black

US$ 11.68 US$ 16.88

: In stock

: 2000544

SPECIAL FEATURES Accurate minus delta voltage (-¦¤V, the so-called voltage drop), ¦¤V/¦¤t, 0¦¤V detecting, ensure fully charging but avoid of over-charging. Pulse charging mechanism provides the best effect and protect...

SPECIAL FEATURES


Accurate minus delta voltage (-¦¤V, the so-called voltage drop), ¦¤V/¦¤t, 0¦¤V detecting, ensure fully charging but avoid of over-charging.
Pulse charging mechanism provides the best effect and protect the battery.
Temperature protection. Detecting the temperature of both the charger and the Batteries. The latter only active for the packages with thermistor built in.
Automatically checking the numbers of batteries (3PCs to 6PCs series connect), automatically adjusting the output voltage.
Accurate constant charging current control.
Perfect short circuit protection and prompt. Current becomes much less than therated charging current when short circuit occurs.
Perfect Battery reverses protection.
Auto repair the over-discharged batteries.
Dual color LED shows the operating condition of the charging progress.
Auto distinguishes the non-rechargeable batteries.
With advanced power controlling skills, make the charger small and light and, the temperature rising is much lower than the opponents





PARAMETERS

INPUT UNIT:
Rated Voltage£ºAC110/220V
Voltage allowed£ºAC90¡ª265V
Rated Freq£º50/60Hz
Rated Current: 100mA (220V full load)
20mA (220V no load)
Max Current: 150mA (220V full load)
30mA (220V no load)



OUTPUT UNIT:
Rated Voltage£ºAutomatically adjust from 3V-9V
Max voltage (with no load): 13V
Rated Current£º1000MA (900mA---1100mA)
Trickle Current: 35--60MA(Pulse ratio 1/20 +10mA)
Short Circuit Current: 30¡ª50mA
Battery repairing Current (Voltage less than 5V): 100-300MA



CONTROL UNIT:
-¦¤V Detect: -5mV
0¦¤V Detect: 50--65S
Temperature protect: Power Supplier IC = 150¡æ
Temperature protect(optional): Battery package 45--60¡æ
Vntc=1.7V Vrecovery=2.0V
Using 10K MF58Z NTC, B=3900
Battery numbers: 3---6 PCs series connected
Pulse ratio: 31/32 512mS/Pirode



ENVIRONMENT:
Ambient Temperature: -10--40¡æ
Ambient Humidity£º 30%--85%
Storage Temp£º-20¡æ--70¡æ
Storage Humidity£º30%--90%



Technical specifications
Input 100~240Vac 47/63Hz
VOLTAGE Change Automatically Between 1.2N-1.6N
Charging Mode IC Control
Timer 6/10 Hours
LED Green Light¡ªNot Connected to The Battery or Fully Charged, Red Light¡ªCharging
Efficiency >80% (Max.load)
Temperature -10--40¡æ
Ambient Humidity 30%--85%
Storage Temp -20¡æ--70¡æ
Storage Humidity 30%--90%
Certification CE-LVD,CE-EMC, FCC, 3C, UL
Drop Test 1M Drop 3 Time
Input Plug CN Plug,US Plug,EU Plug,UK Plug,AU Plug,KC Plug



Model NH060090 NH090055 NH120040 NH150035 NH180030 NH240020
Batteries 2-4 3-6 4-8 5-10 6-12 8-16
Rated Current 0.9 0.55 0.4 0.35 0.3 0.2
Rated Output
2.4-6.4 3.6-9.6 4.8-12.8 6-16 7.2-19.2 9.6-25.6
Vmax @ I=0 8 12 16 20 24 32
Trickle Current 0.05 0.03 0.02 0.018 0.015
0.01
