3.2" 3.2 inch 240X400 TFT LCD Touch Screen Expansion Shield LED Display Module 5V / 3.3V With Touch Pen For Arduino

US$ 9.01

: In stock

:

    Description:   100% brand new and high quality Material: Electrical components Color: See pictures This is a 3.2 inch TFT touch screen expansion board using standard for Arduino...





HTB1v0jRi_nI8KJjy0Ffq6AdoVXaf

Description:

100% brand new and high quality
Material: Electrical components
Color: See pictures
This is a 3.2 inch TFT touch screen expansion board using standard for Arduino Shield interface and it has good compatibility.
It integrates a 3.2-inch touch screen, I2C temperature sensor, TF card holder, level conversion circuit, and the secondary development is easy.
With GPRS module, you can design your for Arduino phone.
With NFC reader module, you can create access control systems with the photos show.
With voltage and current sensor, you can make oscilloscope.
Can use it directly to display characters, graphics and BMP format images. And touch controlling is available;
Compatibility: As the SD card is connected to SPI pins of ICSP interface, compatible with for Arduino UNO R3 / for Arduino Mega2560 / for Arduino Leonardo
Touch screen type: resistive touchscreen.
Touch Pen: length is 9cm;
Resolution: 240X400;
Display size: 3.2 inch;
Operating voltage: 5V;
Logic level: 5V / 3.3V;
On-board 3.3V / 300mA regulator circuit;
Operating current: the maximum is 150mA
Use the A0 ~ A3 pins, D4 ~ D13 pins. And I2C interface, D0 / D1 / D2 / D3 is available, please refer to the product schematics for the details.
Onboard Micro SD slot, support Micro SD / TF Card;
Onboard LM75 temperature sensor: default I2C address is 0X48, scale is -55 ~ 125'C
Very suitable for digital photo frame, oscilloscope, function generator, detection system monitor
Size: 9*5.3cm/3.54"*2.09"


Package includes:

1 x Shield
1 x Touch pen
