1M SC APC UPC FC APC Optical Fiber Patch Cord 3.0mm PVC G652D Fiber Jumper Simplex SM FTTH Optic Cable Fibra Optica
Product Description
OVEVIEW:
Fiber Optic Patch Cable is also known as fiber optic jumper or fiber optic patch cord. Fiber Optic Patch Cable is important of optical network. They have same or different connectors which are installed on the end of fiber optic cable. Fiber optic patch cables are used in two major application areas: computer work station to outlet and patch panels or optical cross connect distribution center. The Fiber Optic Patch Cord series comes with a comprehensive collection of lengths and connectors to fulfill your demand for the deployment.
FEATURES:
* Screw-thread coupling mechanism
* Ceramic ferrules
* Low insertion loss, high return loss
* Good in repeatability and exchangeability
* 100% Insertion, Return Loss, End Face and Interference inspection
* Excellent mechanical endurance
* High credibility and stability
* Complying with Telcordia ,GR-326-Core, IEC and RoHS Standard
* Ceramic ferrules
* Low insertion loss, high return loss
* Good in repeatability and exchangeability
* 100% Insertion, Return Loss, End Face and Interference inspection
* Excellent mechanical endurance
* High credibility and stability
* Complying with Telcordia ,GR-326-Core, IEC and RoHS Standard
SPECIFICATION:
Parameter |
unit |
FC,SC,LC |
ST,MU |
MT-RJ,MPO |
E2000 |
||||||||
Single mode |
Multimode |
Single mode |
Multimode |
Single mode |
Multimode |
Single mode |
|||||||
PC |
UPC |
APC |
PC |
PC |
UPC |
PC |
PC |
UPC |
PC |
PC |
APC |
||
Insertion loss |
dB |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
≤0.2 |
≤0.3 |
Return loss |
dB |
≥45 |
≥50 |
≥60 |
≥30 |
≥45 |
≥50 |
≥30 |
≥45 |
≥50 |
≥35 |
≥55 |
≥75 |
Working wavelength |
nm |
1310. 1550 |
1310. 1550 |
1310. 1550 |
1310. 1550 |
||||||||
Interchangeability |
dB |
≤0.2 |
≤0.2 |
≤0.2 |
≤0.2 |
||||||||
Vibration |
dB |
≤0.2 |
≤0.2 |
≤0.2 |
≤0.2 |
||||||||
Operating temperature |
℃ |
-40~+75 |
-40~+75 |
-40~+75 |
-40~+75 |
||||||||
Storage temperature |
℃ |
-40~+75 |
-40~+75 |
-40~+75 |
-40~+75 |
||||||||
Optical cable outer diameter |
mm |
3.0,2.0, 0.9 |
3.0,2.0, 0.9 |
3.0,2.0,0.9 |
3.0,2.0,0.9 |
||||||||
